Hydraulic Auger Driver
Rotation speed of auger drive and descending
speed of drill rod
is so important for rock drilling over
1 meter
holes.
The rotation speed of our Hydraulic Auger Drive can be
controlled from
0.5 rpm to 23 rpm with automatic control of
descending speed of drill rod.
The advantages of Hydraulic Auger Drive
are less
consumption of
diesel (about 60%), DTH bit buttons and
accurate drilling for the straightness of hole.
|
|
|
|
|
|
|
|
|
MODEL
|
HT-HA 1000
|
MODEL
|
HT-CA 1000
|
|
SCREW Ø
|
Ø300MM TO Ø1000MM
|
CASING Ø
|
Ø400MM TO Ø1000MM
|
POWER
|
100-600HP
|
|
OUTPUT TORQUE
|
3 TO 20TON
|
OUTPUT TORQUE
|
15 TO 80TON
|
PRESSURE
|
MAX 350 BAR
|
|
OUTPUT ROTATION
|
8 TO 30 RPM
|
OUTPUT ROTATION
|
4 TO 10 RPM
|
OIL FLOW
|
100 – 700/MIN
|
|
